White 480mm 12V Caravan Fridge Vent with Triple Fans
$90.00
Order within
for dispatch Today!100 in stock
The White 480mm 12V Caravan Fridge Vent with Triple Fans provides powered ventilation for caravan, motorhome and RV fridge compartments, helping extract built-up warm air from behind the refrigerator. Featuring two 140mm outer fans and one 120mm centre fan operating simultaneously, this 12V caravan fridge vent combines approximately 259 CFM combined nominal fan airflow, quiet operation and an anti-UV ABS exterior grille in a compact 479 × 189mm design.
Why Choose the White 480mm Caravan Fridge Vent?
| ✓ | Triple-Fan Ventilation Two 140mm outer fans and one 120mm centre fan operate simultaneously to help move warm air from the fridge compartment. |
| ✓ | Approx. 259 CFM Combined Nominal Airflow Based on the manufacturer’s individual fan airflow testing without insect mesh. |
| ✓ | Quiet Operation Approximately 30.1 dB(A) measured at 1 metre for low-noise fridge compartment ventilation. |
| ✓ | 12V DC Operation Designed for caravan and RV electrical systems with installer-connected ON/OFF control. |
| ✓ | Extraction Configuration Fans are supplied configured to extract warm air from inside the fridge compartment to outside. |
| ✓ | Anti-UV ABS Construction Durable exterior grille and housing manufactured from anti-UV ABS. |
| ✓ | Replaceable Individual Fans Each fan can be replaced individually if required. |
White 480mm Caravan Fridge Vent Specifications
| Specification | Details |
|---|---|
| SKU | TRA-VF480W |
| Colour | White |
| Voltage | 12V DC |
| Fan Configuration | 2 × 140 × 140 × 25mm outer fans + 1 × 120 × 120 × 25mm centre fan |
| Fan Operation | All three fans operate simultaneously |
| Fan Speed | Outer fans approx. 2,000 RPM each; centre fan 1,850 RPM |
| Airflow | Approx. 259 CFM combined nominal airflow* |
| Noise Level | Approx. 30.1 dB(A) at 1 metre |
| Continuous Current | Approx. 0.4A at 12V |
| Start-Up Requirement | 12V supply capable of at least 1A |
| Recommended Fuse | 5A |
| Recommended Wire Size | Minimum UL2468 AWG 18 |
| Overall Dimensions | 479 × 189 × 55mm |
| Required Cut-Out | 450 × 155mm |
| Minimum Wall Thickness | 47mm |
| Material | Anti-UV ABS |
| Operating Temperature | -5°C to 50°C |
| Estimated Fan Life | Approx. 50,000 hours** |
| Replaceable Fans | Yes – individual fans are replaceable |
| Tested IP Rating | No tested IP rating specified |
*Manufacturer testing without insect mesh measured approximately 96 CFM from each 140mm outer fan and 66.71 CFM from the 120mm centre fan. Approx. 259 CFM represents the combined nominal total of these individual measurements and is not a separately tested complete-unit airflow figure.
**Manufacturer estimated life expectancy under stated operating conditions of 30°C and 15–65% relative humidity.
Ideal Applications
| Installation & Fitment
|
Important fitment note: The fans are supplied configured to extract air from inside the fridge compartment to outside. The manufacturer advises that the fan direction can be physically reversed if intake operation is required. The vent does not have a tested IP/weather-resistance rating. The manufacturer recommends structural adhesive/sealant around the perimeter together with screw fixing. Correct positioning and sealing are important for exterior installations.
What’s Included
| ✓ | 1 × White 480mm 12V Caravan Fridge Vent with Triple Fans |
| ✓ | Mounting screws |
| ✓ | Decorative screw caps |
💡 TRA Expert Tip
Effective caravan fridge ventilation depends on having a clear airflow path through the compartment. Before installation, confirm the 450 × 155mm cut-out, minimum 47mm wall thickness and available airflow path around the refrigerator. TRA Australia recommends professional installation by an appropriately licensed installer.
Find the Right RV Fan & Ventilation SolutionExplore TRA Australia’s range of caravan and RV fans and ventilation products.View RV Fans & Ventilation
Frequently Asked Questions about the White 480mm Caravan Fridge Vent
What size cut-out does the White 480mm Caravan Fridge Vent require?
How much airflow does the VF480W provide?
Do all three fans operate at the same time?
Does the fridge vent have a thermostat or automatic temperature control?
Does the VF480W extract hot air from the fridge compartment?
How loud are the fans?
What fuse and wire size are recommended?
What is the minimum installation wall thickness?
Can the individual fans be replaced?
Does the VF480W have an IP rating?
What is supplied with the VF480W?
